EX-FLH Linear
Class I, Division 2 Linear
Slim linear · 1700 K to 7500 K · 240° tilt · 6063 aluminum · ceiling or pendant
A specialist replies within one business day with budgetary pricing, lead time and the spec match for your area.
Key Features- Available in 1–4 ft lengths (5 W–45 W)
- Easy 240° tilt adjustment with a 3 mm hex key
- Rugged 6063 aluminum housing with stainless steel fasteners
- Clear or frosted glass / polycarbonate diffuser options
Product Description
The FLH Series Linear Light uses LED sources in a minimalist, low-profile form with highly flexible modular connectivity, available in a wide range of lengths and wattages — from short accent runs to continuous industrial task lighting. It delivers up to 124 lm/W across a 1700K–7500K colour-temperature range and is rated explosion-proof for Class I Division 2, and dust-ignition-proof for Class II Division 2 and Class III.
Class I, Division 2 covers hazardous gas and vapour environments where ignitable concentrations are present only under abnormal conditions; Class II, Division 2 adds combustible-dust locations. Typical applications include oil & gas processing, petrochemical and chemical plants, wastewater treatment, food & beverage, and power generation.
For full electrical, photometric, and mechanical specifications — including IP rating, mounting options, ambient-temperature range, certifications, and ordering codes — download the spec sheet linked above.
Technical specifications
From the published spec sheet. Ordering guide, dimensions and packing data are in the PDF.
| Series | FLH, 1 to 4 ft lengths |
|---|---|
| Hazardous rating | Class I, Division 2, Groups A, B, C, D · Class II, Division 2, Groups F, G · Class III |
| Housing | 6063 aluminum, stainless steel fasteners |
| Rated power | 5 to 45 W, by length |
|---|---|
| Efficacy | 110 lm/W on AC · 124 lm/W on DC |
| Colour temperature | 1700 K to 7500 K |
| Mounting | Ceiling, pendant · 240° tilt with a 3 mm hex key |
|---|---|
| Diffuser / lens | Clear or frosted, glass or polycarbonate |
| Beam angle | T2 60°, T3 90°, T5 120° |
| Lengths | 1, 2, 3, 4 ft |
Class I, Division 2 area, site photographyDownloads
