I2EX-I Linear
Class II, Division 1 Linear
130 lm/W · adjustable power and CCT · ceiling, pole, wall, chain, pendant
A specialist replies within one business day with budgetary pricing, lead time and the spec match for your area.
Key Features- Power box can be opened from the side by opening the M75 circular cover, convenient for installation and maintenance, significantly saving manpower and installation time
- Stainless-steel hardware, great anti-corrosion
- Copper-free aluminum housing, excellent corrosion resistance and cooling performance
- High-quality SMT LED, efficacy up to 130 lumens per watt
Product Description
The EX-I Series LED luminaire is a dust-ignition-proof choice for marine and hazardous applications where a linear design is required. And the power and color temperature can be adjusted. Featuring the design of structure, the power box can be opened from the side by opening the M75 circular cover, without the need to loosen multiple screws, easy and convenient for installation and maintenance.
Class II, Division 1 covers areas where combustible dust is present continuously or intermittently during normal operation — typical applications include grain elevators, flour and feed mills, coal handling, and metal-powder plants.
For full electrical, photometric, and mechanical specifications — including IP rating, mounting options, ambient-temperature range, certifications, and ordering codes — download the spec sheet linked above.
Technical specifications
From the published spec sheet. Ordering guide, dimensions and packing data are in the PDF.
| Series | EX-I2 (20 to 100 W), EX-I4 (20 to 200 W) |
|---|---|
| Hazardous rating | Class I, Division 1, Groups C, D · Class I, Division 2, Groups A, B, C, D · Class II, Division 1, Groups E, F, G · Class II, Division 2, Groups E, F, G · Class III |
| Listings and standards | UL 844 |
| Housing | Copper-free aluminum · side-opening M75 power box |
| Warranty | 5 years · L70 > 150,000 hours at 55 °C |
| Rated power | I2: 20 to 100 W · I4: 20 to 200 W · three power levels set by DIP switch |
|---|---|
| Input voltage | 120-277 V AC |
| Lumen output | I2: 3,900 to 13,000 lm · I4: 3,900 to 26,000 lm |
| Efficacy | 130 lm/W |
| Colour temperature | 4000 K, 5000 K, 6000 K, adjustable |
| CRI | > 70 |
| Dimming | 0/1-10 V |
| Emergency backup | Optional, 1.5 hours |
| Mounting | Ceiling, pole, wall, chain, pendant |
|---|---|
| Diffuser / lens | Clear diffused tempered glass |
| Beam angle | 120° |
| Ingress protection | IP66 |
|---|---|
| Impact rating | IK08 |
| Ambient temperature | −40 °C to +40 °C (T6) · +60 °C (T5) · +66 °C (T4) |
Class II, Division 1 area, site photographyDownloads
Photometric Files (IES)
IES photometric files for lighting design and layout in DIALux, AGi32, Visual, and other tools. Download the model that matches your wattage, optic, and voltage. 18 IES files
I2
I4
